The Lamina FA Blackline 1600/800 is a fully automatic, high speed sheet-to-sheet laminating/mounting machine designed for one operator. The machine model is constructed with high capacity feeders for top and bottom sheets that can be reloaded directly on pallets.- Read More -
Up to 5000 sheets/hour
Suction cup picker for top and bottom feeder
800mm Top feeder - 1600mm Bottom feeder
Machine Video demo
PRESSURE BELT UNIT
Enhances the bonding and finish for a flat and smooth final product; recommended for the production of 2-ply/open-fluted corrugated material- Read More -
Fully AUTO system that down stacks final product flat and perfectly formatted on the pallet ready for the next production phase. Even short orders with quickly growing stacks are no problem for the Stacker. Reduces manpower and downtime- Read More -
FLIP FLOP UNIT
Fully AUTO system that turns the product 180 degrees periodically during production, to deliver a perfectly flat-drying final product – eliminates end-product warping. Ideal for double-sided production. Reduces manpower and downtime- Read More -
Foam suction cup unit/system for ‘picking’ 2-ply/open fluted corrugated material(s)- Read More -
NON-STOP STACKER UNIT
Allows unloading of perfectly formatted palleted stacks without halting production for the unloading phase. The reloading of empty pallets in the unit is also achieved during this process. Reduces manpower and downtime- Read More -
State-of-the-art system that detects multiple sheets. Perfect for double-sided production runs- Read More -
For quick and easy loading, and accurate positioning of palleted material(s) in our high capacity feeders eliminating loading down time- Read More -
Application of glue to specific areas of the substrate and not the total surface area of the board- Read More -
BLACKLINE - HIGH CAPACITY
The Lamina FA Blackline 1600/800 is a fully automatic, high speed sheet-to-sheet laminating/mounting machine designed for one operator. The machine model is constructed with high capacity feeders for top and bottom sheets that can be reloaded directly on pallets.
Because of the compact construction it is a very operator friendly machine with quick set-ups and easy handling. The machine can handle most of the materials on the market with a high output and
perfect registration. Lamina FA Blackline can be upgraded with several options such as Pressure Belt, Downstacker, Flip-Flop, Single Face Feeder etc.
A Lamina Model BLACKLINE FA sheet laminator
For sheet-to-sheet laminating of paper and cardboard-to-cardboard, solid and corrugated.
The machine features a modular construction which combines a rigid framework with modern anodized alumininum profiles resulting in a heavy-duty, yet attractive unit that will give many years of dependable service. Set up and changeover are accomplished quickly and easily from the operator side without the use of tools. A combination of mechanical and photocell controls results in consistent registration accuracy of less than ± 0,5 mm when proper materials and conditions exist.
Lamina's laminating machine type FA is equipped with:
- Automatic substrate rear edge sheet feeder
- Automatic top sheet rear edge feeder
- Precision gluing unit with automatic glue application
- Laminating station with automatic front and side registration system
- Pressure station
- Stacking table
- PLC control system
Automatic substrate sheet feeder
For automatic feeding of the bottom sheet. Suction cups pick up the bottom sheet from the rear edge of the stack and transfer it to the precision gluing unit. The full line of suction cups is easy to move on a guide for a quick set-up. The feeder is designed to handle materials from 250 gm/m2 with a thickness of 0,6 - 10 mm.
Automatic top sheet feeder
For automatic feeding of top sheets. Suction cups pick up the top sheet from the rear edge of the stack and transport it to the top sheet conveyor. The full line of suction cups is easy to move on a guide for a quick set-up. The feeder is designed to handle materials 130-450gm/m2.
Precision gluing unit
The gluing units for accurate application of cold PVA glue to the upper surface of the substrates are equipped with automatic glue dispensers directly connected to the glue container. The film thickness of the glue is automatically kept under control irrespective of the sheet (board) thickness. During machine standstill the rotation speed of the rollers is reduced to a low idling speed. The precision gluing unit can be made fully accessible for easy cleaning by vertically swinging the top and bottom sheet conveyors up and out of the way.
In the automatic laminating station, the top and bottom sheets are automatically controlled by the registration system. The sheets are registered automatically at the edge as well as at the operator side, resulting in accuracy levels less than +/- 0,5 mm. Photocells prevent the lamination process unless both sheets are properly positioned.
This unit consists of an adjustable press roller system ensuring perfect lamination.
For the stacking of finished products. The table can be turned and pulled out acc to requirements.
PLC control system
The Lamina PLC control system includes: Touch screen monitor, continuous display of operating status, display of set up procedures for machine functions, touch screen activation of controlled machine functions and complete diagnostic screen with visual alarm.
